Maxilift 180 Series

180 SERIES

Standard outreach: from 9’10” to 13’2″
330° slewing rotation with worm screw
4 functions valve bank



Including

  • 15 lt. oil tank for H (P.T.O. – Power Take Off) version
  • Motor pump kit with 11 lt. oil tank for electro-hydraulic versions E12/24V (along with battery connection cables)
  • Tie bolts set, nuts and lock nuts
  • Spare grease cartridge for slewing worm gear

Options

  • Crane base with 1 hydraulic and 1 mechanical stabilizers (fix or tilting)
  • Crane base with 2 hydraulic stabilizers (fix or tilting)
  • 3 – 4 functions proportional remote control (by cable or radio)
  • 500 kg hydraulic winch – New system with less cumbersome snatch block and quick disconnecting stop end system

FULL CAPACITY

180.2

Crane rating: ft lb 12.550
Standard outreach: ft 9′ 11″
Standard hydraulic extensions: n° 2

Maximum angle slope: °5

Suggested oil flow: gpm 1.6÷2.1

Max. working pressure: p.s.i. 3045
Basic crane weight “ers” 12v/24v: lb 440
Basic crane weight “h”: lb 395

Base weight with extendable stabilizers: lb 225÷240
Beam weight with 2 extendable stabilizers: lb 150÷180

180.3

Crane rating: ft lb 12.550
Standard outreach: ft 13′ 1″
Standard hydraulic extensions: n° 3

Maximum angle slope: °5

Suggested oil flow: gpm 1.6÷2.1

Max. working pressure: p.s.i. 3045
Basic crane weight “ers” 12v/24v: lb 460
Basic crane weight “h”: lb 420

Base weight with extendable stabilizers: lb 225÷240
Beam weight with 2 extendable stabilizers: lb 150÷180

OPTIONALS

Slewing angle limitation

Winch

Cable remote control

Radio remote control

Additional function

Colour

Personalized colour on request (standard colour red RAL 3020)

Micro-switch for extension

Micro-switch kit signalling not locked side extension.

Beam 2H

Main beam 1H

Main beam 1H+1M

Main beam 1M

Titling stabilisers

Mechanical stabiliser

Tilting kit

Side handle leg

Manual extensions

Fixed installation
